With the development of the automotive industry and vehicle technology to improve the design and manufacturing process of the drive axle are increasingly improved. Drive Axle and other automotive assembly, in addition to the widespread adoption of new technology in the structural design, the direction of development and production organizations increasingly toward "standardization of parts, components universal product series" professional goal.
This manual, according to the given parameters, the first main gear box design. The structure of the main gear box, and the geometric dimensions of the design. The main gear box in the form of single-stage main gear box and two-stage main gear box. Final drive gear mainly in the form of spiral bevel gears, hypoid gears, cylindrical gears, worm and other forms. This design is integral single-stage main gear box, gear forms of hypoid gears. Secondly, in the form of differential selection, differential forms are divided into ordinary symmetric cone planetary gear differential and limited slip differential two. The design uses a common symmetric cone planetary gear differential. Finally, on the structure of the axle, supporting forms, and the axle housing forms and characteristics of the analysis and design. The design uses a full floating axle shaft bearing and the overall drive axle housing.After finishing the whole design,I use AUTOCAD and SOLIDWORKS to draw 2-D and 3-D pictures.
Keywords: Drive axle、Main reducer、Differential、AUTOCAD、SOLIDWORKS
...
